OM SYSTEM OM-5 Mirrorless Camera Body (Silver)
- 20.4MP Live MOS Micro Four Thirds Sensor
- TruePic IX Image Processor
- 2.36m-Dot Eye-Level OLED EVF
- 3.0" 1.04m-Dot Vari-Angle Touchscreen
- DCI 4K/24p & UHD 4K/30p Video Recording
- 5-Axis Sensor-Shift Image Stabilization
- 30 fps Shooting, ISO 200-25600
- 121-Point All Cross-Type Phase-Detect AF
- High-Res Shot, Live ND & Composite Modes
- Weather-Sealed Construction
Discontinued. No Longer Available

Description
Specifications
|
Imaging |
|
|
Lens Mount |
Micro Four Thirds |
|
Effective Sensor Resolution |
Effective: 20.4 Megapixel (5184 x 3888) |
|
Image Sensor |
17.4 x 13 mm (Four Thirds) MOS |
|
Sensor Crop (35mm Equivalent) |
Crop Factor: 2x |
|
Image Stabilization |
Sensor-Shift, 5-Axis |
|
Built-In ND Filter |
No |
|
Capture Type |
Stills & Video |
|
Exposure Control |
|
|
Shutter Type |
Mechanical Focal Plane Shutter and Electronic Rolling Shutter |
|
Shutter Speed |
Electronic Shutter |
|
Bulb/Time Mode |
Bulb & Time Mode |
|
ISO/Gain Sensitivity |
Photo |
|
Metering Method |
Center-Weighted Average, Highlight, Multi-Zone, Spot |
|
Exposure Modes |
Aperture Priority, Auto, Manual, Program, Shutter Priority |
|
Exposure Compensation |
-5 to +5 EV (1/3, 1/2, 1 EV Steps) |
|
Metering Range |
-2 to 20 EV |
|
White Balance |
2000 to 14,000K |
|
Continuous Shooting |
Up to 30 fps at Maximum Resolution |
|
Interval Recording |
Yes |
|
Self-Timer |
2/12-Second Delay |
|
Still Image Capture |
|
|
Aspect Ratio |
1:1, 3:2, 4:3, 16:9 |
|
Image File Format |
JPEG, Raw |
|
Bit Depth |
12-Bit |
|
Video Capture |
|
|
Internal Recording |
H.264/MPEG-4 AVC/MOV |
|
Video Output |
HDMI |
|
Fast-/Slow-Motion Support |
Yes |
|
Recording Limit |
No |
|
IP Streaming |
No |
|
Built-In Microphone |
Stereo |
|
Interface |
|
|
Media/Memory Card Slot |
Single Slot: SD/SDHC/SDXC (UHS-II) |
|
Internal Storage |
No |
|
Video I/O |
1x Micro-HDMI Output |
|
Audio I/O |
1x 1/8" / 3.5 mm TRS Stereo Microphone Input |
|
Power I/O |
1x Micro-USB Input/Output |
|
Other I/O |
1x 2.5 mm Sub-Mini Data Input |
|
Wireless |
802.11a/b/g Wi-Fi / Bluetooth 4.2 |
|
Mobile App Compatible |
Yes: Android & iOS |
|
Global Positioning (GPS, GLONASS, etc.) |
GPS |
|
Monitor |
|
|
Display Type |
Articulating 3" Touchscreen LCD |
|
Resolution |
1,040,000 Dot |
|
Viewfinder |
|
|
Type |
Electronic (OLED) |
|
Resolution |
2,360,000 Dot |
|
Eye Point |
27 mm |
|
Coverage |
100% |
|
Diopter Adjustment |
-4 to +2 |
|
Focus |
|
|
Focus Type |
Auto and Manual Focus |
|
Focus Mode |
Continuous-Servo AF, Manual Focus, Single-Servo AF |
|
Autofocus Points |
Contrast Detection, Phase Detection: 121 (121 Cross-Type) |
|
Flash |
|
|
Built-In Flash/Light |
No |
|
Flash Modes |
Fill Flash, Manual, Off, Red-Eye Reduction, Second-Curtain Sync, Slow Sync, Slow Sync/Red-Eye Reduction |
|
Maximum Sync Speed |
1/250 Second |
|
Flash Compensation |
-3 to +3 EV (1/3, 1 EV Steps) |
|
Dedicated Flash System |
TTL |
|
External Flash Connection |
Shoe Mount |
|
General |
|
|
Battery |
1x BLS-50 Rechargeable (Included) |
|
Shoe Mount |
1x Hot Shoe |
|
Tripod Mount |
1x 1/4"-20 Female (Bottom) |
|
Operating Conditions |
14 to 104°F / -10 to 40°C at 30 to 90% Humidity |
|
Storage Conditions |
-4 to 140°F / -20 to 60°C at 10 to 90% Humidity |
|
Dimensions (W x H x D) |
4.9 x 3.4 x 2" / 125.3 x 85.2 x 49.7 mm |
|
Weight |
12.9 oz / 366 g (Body Only) |
